LITTEL MULTI-SWITCH – SERIES 35000
FAX: 773 792-2129
?
SWITCHES
303
* Please visit the product pages on our website for the most up-to-date product information
MULTIPLE-STATION SWITCHES (continued)
LITTEL ? MULTI-SWITCH
SERIES 35000
SERIES 35000
Specify 1 to 18 stations (non-illuminated) with a large
selection of mechanical functions, choice of pushbuttons,
and up to 6 poles of switching per station. Plungers are on
.625" (15.88 mm) centers and are made from .050" (1.27
mm) x .187" (4.75 mm) steel. A square black pushbutton,
A592, is supplied with each station. A wide variety of
special mechanical functions, features and accessories
are also available.
ORDERING INFORMATION
STANDARD SWITCHES
Order by part number from tables.
SPECIAL SWITCHES
Many special mechanical functions, features and
accessories are available. Contact Switchcraft.
? Ganged Assemblies ? Pushbuttons
? Special Mechanical Functions ? Legends
? Switch Stacks ? Accessories
TYPICAL PANELS DIMENSIONS
SERIES 35000
PART NUMBERS/2-C PER STATION 1
? PC and Wire-Wrapping Terminals
Interlock
Push-Lock/
Number of
with Lock-Out
35021K206
35041K206
35061K206
35081K206
35101K206
35121K206
Non-Lock
? 35022206
? 35042206
? 35062206
? 35082206
? 35102206
? 35122206
Push-Release
? 35027206
? 35047206
? 35067206
? 35087206
? 35107206
? 35127206
Stations 2
2
4
6
8
10
12
PART NUMBERS/4-C PER STATION 1
? 35021K212
? 35022212
? 35027212
2
FIGURE A - PANEL CUTOUT FOR
PLUNGER CLEARANCE ONLY
? 35041K212
? 35061K212
? 35081K212
? 35101K212
? 35121K212
? 35042212
? 35062212
? 35082212
? 35102212
? 35122212
? 35047212
? 35067212
? 35087212
? 35107212
? 35127212
4
6
8
10
12
1. Switches with all-lock function are available on special order. Contact
Switchcraft.
2. Odd number of stations (3, 5, 7, 9, 11) are available. Switches with
13 through 18 stations are also available. Contact Switchcraft.
? Special order only; Contact Switchcraft for price and delivery information.
FIGURE B - PANEL CUTOUT FOR
SERIES A590 PUSHBUTTON CLEARANCE ONLY
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
